Volkswagen B3 Passat
Body Exterior
Body dimensions, floor
Volkswagen B3 Passat
Body Exterior
Body dimensions, front
Volkswagen B3 Passat
Body Exterior
Body dimensions, front
Volkswagen B3 Passat
Body Exterior
Body dimensions, front
Volkswagen B3 Passat
Body Exterior
Body dimensions, side
Volkswagen B3 Passat
Body Exterior
Body dimensions, side
Volkswagen B3 Passat
Body Exterior
Body dimensions, rear: Sedan
Volkswagen B3 Passat
Body Exterior
Body dimensions, rear: Wagon
Volkswagen B3 Passat
Body Exterior
Lock carrier with front panel, assembly
1 - Bolt - 12 Nm (8.9 ft lb)
self locking, clean bolt threads with wire brush, nut threads with tap and coat with
AMV 197 000 01 prior to reinstalling
2 - Retaining clip
3 - Edge protectors, fenders
4 - Screw - 5.0 Nm (44 in. lb)
self tapping.
5 - Lock carrier with front panel
